EAN: 06170103
Torrent Dual Colour Lightbar, 1252mm (49.3″), 48x AMBER/BLUE LEDs, CLEAR LENSES (SHORT), ECE R10, IPX4K, D-Fuser Optics, 21 Flash Patterns, 2 Cable Harness (16 Function/4 Power), Standard Feet, 24VDC.
-
Specifications
Aerodynamic shape for minimum air resistance and wind shear.
Low-profile design, with a solid, sturdy look to best fit your vehicle.
New linear D-fuser technology with powerful SAE/CA13/ECE R10 approved performance.
Solid top and base aluminium plates for best rigidity and heat dissipation.
Built-in rear traffic director function.ShortProduct Specifications
Product code 06170103 Product Name Torrent DC 1252mm (49.3") - AB (Short Lens/24VDC) Categories Warning Lamps, Lightbars, Torrent Dual Colour, Torrent Configurations (available Cruise Light, Alley Lights, Take-Downs, Traffic Director, Illuminated Centre, Steady On Default Functions Hi/Low Power (50%, Traffic Director - Rear Left Arrow., Traffic Director - Rear Right Arrow., Right-Side Alley Light, Left-Side Alley Light, Flashing Alleys & Take-Downs, Front Cut-Off, Rear Cut-Off, Program Mode, Take-Down Lights (2 heads, ECE-R65 Warning Mode, Flash Pattern for LEDs & TD/Alley Dimensions Height 67mm (2.6") Dimensions Width 317mm (12.4") Colour Type Dual Colour Maximum Current 9.2A@25.6VDC Operating Temperature -30°C~+65°C Lightbar Length 1252mm (49.3") LED Colour Amber LEDs, Blue LEDs Fuse Rating 20A Lens Colour Clear Lens Compliance ECE-R10, SAE J845 Class 1, CA13 Input Voltage 24VDC Optic Type D-Fuser Optics Mounting Option Standard Bolt Mount Brackets Cable Type 2 Cable Harness (16 Function/4 Power) LED Quantity 48x LEDs Lighthead Quantity 4x Lightheads Flash Patterns 17 Flash Patterns IP Rating IPX4K Traffic Arrow Patterns 11 Traffic Arrow Gross Weight 16.4kg Dummy Bracket Qty 16x Dummy Plates Warranty 5 Year Warranty -
Spare Parts
-
- Alley
- Single Colour
- 2 Pin Connector
- White LEDs
- Spot Optics
-
- Take-Down
- Single Colour
- 2 Pin Connector
- White LEDs
- Spot Optics
-
-
- Take-Down
- Single Colour
- 2 Pin Connector
- White LEDs
- Spot Optics
-
- Warning
- Dual Colour
- 3 Pin Connector
- Amber LEDs, Blue LEDs
- Clear Lens
-
-
-
-
-
-
- Warning
- Dual Colour
- 3 Pin Connector
- Amber LEDs, Blue LEDs
- Clear Lens
-
