Torrent 1372mm (54") - BC (Short Lens/12VDC)

Specifications

Integrated take-down light and alley light options.
Solid aluminium body for best durability and heat dissipation.
Programmable flash patterns with optional traffic arrow and stop/tail/turn function.
Reverse polarity protection.
ECE R10 EMC Compliance.

Product Specifications

Product code	06151270
Product Name	Torrent 1372mm (54") - BC (Short Lens/12VDC)
Categories	Warning Lamps, Lightbars, Torrent Single Colour, Torrent
Product Type	Products
Configurations (available	Illuminated Centre, Steady On, Cruise Light, Alley Lights, Take-Downs, Traffic Director, Stop / Tail / Turn
Default Functions	Right-Side Alley Light, Left-Side Alley Light, Illuminated Centre Section, Flashing Alleys & Take-Downs, Front Cut-Off, Rear Cut-Off, Program Mode, Take-Down Lights (2 heads, Hi/Low Power (50%, Traffic Director - Rear Left Arrow., Traffic Director - Rear Right Arrow., Stop / Tail / Turn, Control Box Transmission Line, Cruise Light Mode, ECE-R65 Warning Mode, Flash Pattern for LEDs & TD/Alley
Dimensions Height	67mm
Dimensions Width	317mm
Colour Type	Single Colour
Maximum Current	25.6A@12.8VDC
Storage Temperature	-40°C - +75°C
Operating Temperature	-30°C~+65°C
Lightbar Length	1372mm (54")
LED Colour	Blue LEDs
Fuse Rating	40A
Lens Colour	Clear Lens
Compliance	ECE-R10, ECE-R65 (TB2), SAE J845 Class 1, California Title 13
Input Voltage	12VDC
Optic Type	D-Fuser Optics
Mounting Option	Standard Bolt Mount Brackets
Cable Type	Double Harness (16 Function/4 Power)
LED Quantity	48x LEDs
Lighthead Quantity	4x Lightheads
IP Rating	IPX4K
Flash Patterns	14 Flash Patterns
Traffic Arrow Patterns	11 Traffic Arrow
Dummy Bracket Qty	18x Dummy Plates
Warranty	5 Year Warranty
