EAN: 06150648
Torrent Lightbar, 1252mm (49″), 48x BLUE LEDs, CLEAR LENSES (SHORT), ECE R10, ECE R65 (TB2), IPX4K, D-Fuser Optics, 12 Flash Patterns, Double Harness (16 Function/4 Power), Standard Feet, 24VDC.
-
Specifications
Integrated take-down light and alley light options.
Solid aluminium body for best durability and heat dissipation.
Programmable flash patterns with optional traffic arrow and stop/tail/turn function.
Reverse polarity protection.
ECE R10 EMC Compliance.Product Specifications
Product code 06150648 Product Name Torrent 1252mm (49") - BC (Short Lens/24VDC) Categories Lighting, Lightbars, Torrent Single Colour, Torrent Product Type Products Configurations (available) Alley Lights, Take-Downs, Traffic Director, Stop / Tail / Turn, Illuminated Centre, Steady On, Cruise Light Default Functions Traffic Director - Rear Left Arrow., Take-Down Lights (2 heads, Traffic Director - Rear Right Arrow., Hi/Low Power (50%), Right-Side Alley Light, Left-Side Alley Light, Flashing Alleys & Take-Downs, Illuminated Centre Section, Front Cut-Off, Rear Cut-Off, Program Mode, Stop / Tail / Turn, Control Box Transmission Line, Cruise Light Mode, ECE-R65 Warning Mode, Flash Pattern for LEDs & TD/Alley Dimensions Height 67mm Dimensions Width 317mm Colour Type Single Colour Storage Temperature -40°C - +75°C Maximum Current 11.4A@25.6VDC Operating Temperature -30°C~+65°C Lightbar Length 1252mm (49.5") LED Colour Blue LEDs Fuse Rating 20A Lens Colour Clear Lens Compliance ECE R10, ECE R65 - TB2, SAE J845 Class 1, California Title 13 Input Voltage 24VDC Optic Type D-Fuser Optics Mounting Option Standard Bolt Mount Brackets Cable Type Double Harness (16 Function/4 Power) LED Quantity 48x LEDs Lighthead Quantity 4x Lightheads Flash Patterns 14 Flash Patterns IP Rating IPX4K Traffic Arrow Patterns 11 Traffic Arrow Dummy Bracket Qty 16x Dummy Plates Warranty 5 Year Warranty -
Spare Parts
-
- Lighthead
- Alley
- Single Colour
- 3x LEDs
- 2 Pin Connector
-
- Lighthead
- Take-Down
- Single Colour
- 6x LEDs
- 2 Pin Connector
-
- Lighthead
- Warning
- Single Colour
- 6x LEDs
- 3 Pin Connector
-
- Lighthead
- Take-Down
- Single Colour
- 9x LEDs
- 2 Pin Connector
-
-
-
-
-
-
-
- Lighthead
- Warning
- Single Colour
- 12x LEDs
- 3 Pin Connector
-
-
Mounting
-
- Bracket
- Aluminium
- Low Profile Flat Wide Feet
- Black
-
- Bracket
- Aluminium
- Low Profile Flat Narrow Feet
- Black
-
- Bracket
- Aluminium
- MS3 - Extrusion Bracket
- Black
-
- Bracket
- Aluminium
- MS3 - A006 Mounting Bracket
- Black
-
- Bracket
- Mount Kit (Adjustable A006)
- Black
-
- Bracket
- Aluminium
- Mount Kit (Adjustable Bolt)
- Black
-
- Bracket
- Aluminium
- Low Profile Flat Wide Feet
- Black
-
- Bracket
- Aluminium
- Low Profile Flat Narrow Feet
- Black
-
-
- Downloads
