Torrent 1252mm (49.3") - AC (Long Lens/24VDC)

Specifications

Integrated take-down light and alley light options.
Solid aluminium body for best durability and heat dissipation.
Programmable flash patterns with optional traffic arrow and stop/tail/turn function.
Reverse polarity protection.
ECE R10 EMC Compliance.

Product Specifications

Product code	06150587
Product Name	Torrent 1252mm (49.3") - AC (Long Lens/24VDC)
Categories	Warning Lamps, Lightbars, Torrent Single Colour, Torrent
Product Type	Products
Configurations (available	Cruise Light, Alley Lights, Take-Downs, Traffic Director, Stop / Tail / Turn, Illuminated Centre, Steady On
Default Functions	Traffic Director - Rear Left Arrow., Traffic Director - Rear Right Arrow., Take-Down Lights (2 heads, Right-Side Alley Light, Hi/Low Power (50%, Left-Side Alley Light, Flashing Alleys & Take-Downs, Front Cut-Off, Illuminated Centre Section, Rear Cut-Off, Program Mode, Control Box Transmission Line, Stop / Tail / Turn, Cruise Light Mode, ECE-R65 Warning Mode, Flash Pattern for LEDs & TD/Alley
Dimensions Height	67mm
Dimensions Width	317mm
Colour Type	Single Colour
Storage Temperature	-40°C - +75°C
Maximum Current	11.4A@25.6VDC
Operating Temperature	-30°C~+65°C
Lightbar Length	1252mm (49.3")
LED Colour	Amber LEDs
Fuse Rating	20A
Lens Colour	Clear Lens
Compliance	ECE-R10, ECE-R65 (TA2), SAE J845 Class 1, California Title 13
Input Voltage	24VDC
Optic Type	D-Fuser Optics
Mounting Option	Standard Bolt Mount Brackets
Cable Type	Double Harness (16 Function/4 Power)
LED Quantity	48x LEDs
Lighthead Quantity	4x Lightheads
IP Rating	IPX4K
Flash Patterns	14 Flash Patterns
Traffic Arrow Patterns	11 Traffic Arrow
Dummy Bracket Qty	16x Dummy Plates
Warranty	5 Year Warranty
