Specifications
Super low profile for stealth look.
Lightheads come with waterproof connectors for quick and easy replacement.
Non-volatile memory recalls last flash pattern used at power up.
LEDs rated to 100,000 hours of operation.
Aluminium extrusion for heat dissipation.
Reverse polarity protection.Product Specifications
Product code 01050042 Product Name Rayzr Traffic Director 1103mm - A10 Categories Lighting, Rayzr TR3, Traffic Advisors Product Type Products Dimensions Height 24mm Dimensions Width 38mm Colour Type Single Colour Storage Temperature -40°C - +75°C Maximum Current 4.7A @12.8VDC / 2.4A @ 24VDC Operating Temperature -30°C~+65°C Maximum Power 60.2W Traffic Advisor Length 1103mm LED Colour Amber LEDs Traffic Director Functions Traffic Arrow, Warning Mode, End Flashers Lens Colour Clear Lens Compliance ECE R10, SAE J595 Class 1, SAE J845 Class 1 Input Voltage 12VDC~24VDC Optic Type T.I.R Optics Mounting Option 2-Bolt Mount Cable Type Single Harness (6 Function/2 Power) LED Quantity 30x LEDs Lighthead Quantity 10x Lightheads Flash Patterns 20 Flash Patterns IP Rating IP67 Traffic Arrow Patterns 11 Traffic Arrow Mounting Orientation Horizontal Warranty 5 Year Warranty -
