Specifications
Product Specifications
Product code 01080131 Product Name Rayzr Traffic Director 1103mm - A1A8A1 Categories Lighting, Rayzr TR3, Traffic Advisors Product Type Products Dimensions Height 24mm Dimensions Width 38mm Colour Type Single Colour Maximum Current 4.7A @12.8VDC / 2.4A @ 24VDC Storage Temperature -40°C to +75°C Operating Temperature -30°C to +65°C Maximum Power 60.2W Traffic Advisor Length 1103mm LED Colour Amber LEDs Lens Colour Clear Lens Traffic Director Functions Traffic Arrow, Warning Mode, End Flashers Compliance ECE R10, SAE J595 Class 1, SAE J845 Class 1, California Title 13 Optic Type T.I.R Optics Nominal Voltage 12-24VDC Mounting Option 2-Bolt Mount Cable Type Single Harness (6 Function/2 Power) LED Quantity 30x LEDs Lighthead Quantity 10x Lightheads IP Rating IP67 Flash Patterns 20 Flash Patterns Traffic Arrow Patterns 11 Traffic Arrow Mounting Orientation Horizontal Warranty 5 Year Warranty -
Spare Parts
-
-
Mounting
-
- Downloads
