Specifications
Product Specifications
Product code 01080155 Product Name Rayzr Traffic Director 0888mm - B1R6B1 Categories Lighting, Rayzr TR3, Traffic Advisors Product Type Products Dimensions Height 24mm Dimensions Width 38mm Colour Type Single Colour Maximum Current 3.8A @12.8VDC / 1.9A @ 24VDC Storage Temperature -40°C - +75°C Operating Temperature -30°C~+65°C Maximum Power 48.7W LED Colour Blue LEDs, Red LEDs Lens Colour Clear Lens Traffic Director Functions Traffic Arrow, Warning Mode, End Flashers Compliance ECE R10, SAE J595 Class 1, SAE J845 Class 1, California Title 13 Input Voltage 12VDC~24VDC Optic Type T.I.R Optics Mounting Option 2-Bolt Mount Cable Type Single Harness (6 Function/2 Power) LED Quantity 24x LEDs Lighthead Quantity 8x Lightheads IP Rating IP67 Flash Patterns 20 Flash Patterns Traffic Arrow Patterns 11 Traffic Arrow Mounting Orientation Horizontal Warranty 5 Year Warranty -
Spare Parts
-
-
Mounting
-
- Downloads
