Specifications
Quad memory capability (4-wire cable models only).
Dual Colour lightbar with ECE R65 (TA1/TB2) approval.
Built-in selectable 26 flash patterns and 5 colour modes.
Non-volatile memory recalls last flash pattern used at power up.
Weatherproof and vibration resistant design for all environment usage.
Multi-units synchronization in simultaneous or alternating flash.
Each unit comes with 6 lightheads (12 LEDs/head).
Reverse polarity protection.Product Specifications
Product code 06250058 Product Name Microbar EXD - ABC (4-Bolt Mount) Categories Lighting, Lightbars, Microbar EX, Minibars Product Type Products Dimensions Length 400mm Dimensions Height 37mm Dimensions Width 172mm Colour Type Dual Colour Maximum Current 6A@12VDC / 3A@24VDC Operating Temperature -30°C~+65°C Maximum Power 72W Synchronisation 15 Unit Sync Lightbar Length 0400mm (16") LED Colour Amber LEDs, Blue LEDs Fuse Rating 9A Lens Colour Clear Lens Compliance ECE R10, ECE R65 - TA1, ECE R65 - TB2, SAE J845 Class 1 Nominal Voltage 12-24VDC Mounting Option 4-Bolt Mount Cable Type Cable (Pigtail) LED Quantity 72x LEDs Lighthead Quantity 6x Lightheads Flash Patterns 26 Flash Patterns IP Rating IPX5 Wire Length 300mm Warranty 5 Year Warranty -
