Legion HE H002 Speaker Lightbar, 1252mm (49″), 72x BLUE LEDs, CLEAR LENSES, ECE R10, ECE R65 (TB2), IPX4K, D-Fuser Optics, 12 Flash Patterns, Double Harness (16 Function/4 Power/2 Speaker), Standard Feet, 12VDC.
-
Specifications
Product Specifications
Product code 06260200 Product Name Legion HE H002 Speaker 1252mm (49") - BC (12VDC) Categories Lighting, Lightbars, Legion High End, Legion HE H002 Speaker, Legion Product Type Products Default Functions Take-Down Lights (2 heads, Left-Side Alley Light, Hi/Low Power (50%), Flashing Alleys & Take-Downs, Steady On, Front Cut-Off, Rear Cut-Off, Program Mode, Traffic Director - Rear Left Arrow., Traffic Director - Rear Right Arrow., Right-Side Alley Light, Stop / Tail / Turn, Control Box Transmission Line, ECE-R65 Warning Mode, Flash Pattern for LEDs & TD/Alley Dimensions Height 77mm Speaker Power Rating 100W Dimensions Width 331mm Colour Type Single Colour Lightbar Length 1252mm (49.5") Impedance 10-13 Ohms LED Colour Blue LEDs Lens Colour Clear Lens Compliance ECE R10, ECE R65 - TB2, SAE J595 Class 1, SAE J845 Class 1, California Title 13 Optic Type D-Fuser Optics Nominal Voltage 12VDC Mounting Option Standard Bolt Mount Brackets Cable Type Double Harness (16 Function/4 Power/2 Speaker) LED Quantity 72x LEDs Lighthead Quantity 8x Lightheads IP Rating IPX4K Flash Patterns 12 Flash Patterns Dummy Bracket Qty 4x Dummy Plates Warranty 5 Year Warranty -
