EAN: 06260040
Legion HE H002 Speaker Lightbar, 0935mm (36.8″), 72x AMBER LEDs, CLEAR LENSES, ECE R10, ECE R65 (TA2), IPX4K, D-Fuser Optics, 7 Flash Patterns, 1 Cable Harness (8 Function/2 Power/2 Speaker), Standard Feet, 12VDC.
-
Specifications
Product Specifications
Product code 06260040 Product Name Legion HE H002 Speaker 0935mm (36.8") - AC (12VDC) Categories Warning Lamps, Legion High End, Lightbars, Legion HE H002 Speaker, Legion Dimensions Length 935mm (36") Default Functions Right-Side Alley Light, Left-Side Alley Light, Take-Down Lights (2 heads, ECE-R65 Warning Mode, Flash Pattern for LEDs & TD/Alley Dimensions Height 59mm (2.3") Speaker Power Rating 100W Dimensions Width 331mm (13") Colour Type Single Colour Lightbar Length 0935mm (36.8") Speaker Impedance 10-13 Ohms LED Colour Amber LEDs Lens Colour Clear Lens Compliance ECE-R10, ECE-R65 (TA2), SAE J595 Class 1, SAE J845 Class 1, CA13 Input Voltage 12VDC Optic Type D-Fuser Optics Mounting Option Standard Bolt Mount Brackets Cable Type 1 Cable Harness (8 Function/2 Power/2 Speaker) LED Quantity 72x LEDs Lighthead Quantity 8x Lightheads Flash Patterns 7 Flash Patterns IP Rating IPX4K Warranty 5 Year Warranty -
Spare Parts
-
-
- 100W
- Acrylonitrile Butadiene Styrene (ABS), Aluminium
- 100W
- H002
- 10-13 Ohms
-
-
-
-
- Warning
- Single Colour
- 3 Pin Connector
- Amber LEDs
- D-Fuser Optics
-
- Warning
- Single Colour
- 3 Pin Connector
- Amber LEDs
- D-Fuser Optics
-
-
-
