Legion HE Lightbar, 1087mm (42.8″), 72x GREEN LEDs, CLEAR LENSES, ECE R10, IPX4K, D-Fuser Optics, 12 Flash Patterns, Double Harness (16 Function/4 Power), Standard Feet, 12VDC.
-
Specifications
LEDs rated to 100,000 hours of operation.
Easy maintenance and lighthead replacement.
D-Fuser optics for superior 360 degree light spread.
Non-volatile memory recalls last flash pattern used at power up.
Aluminium extrusion for best heat dissipation.
Built-in and programmable flashing patterns.
Reverse polarity protection.Product Specifications
Product code 06320317 Product Name Legion HE 1087mm (42.8") - GC (12VDC) Categories Warning Lamps, Lightbars, Legion High End, Legion HE Standard, Legion Product Type Products Configurations (available Take-Downs, Traffic Director, Stop / Tail / Turn, Illuminated Centre, Steady On, Cruise Light, Alley Lights Dimensions Length 1087mm (42.8") Default Functions Traffic Director - Rear Left Arrow., Traffic Director - Rear Right Arrow., Right-Side Alley Light, Left-Side Alley Light, Illuminated Centre Section, Flashing Alleys & Take-Downs, Front Cut-Off, Rear Cut-Off, Take-Down Lights (2 heads, Program Mode, Hi/Low Power (50%, Stop / Tail / Turn, Control Box Transmission Line, Cruise Light Mode, ECE-R65 Warning Mode, Flash Pattern for LEDs & TD/Alley Dimensions Height 59mm (2.3") Dimensions Width 331mm (13") Colour Type Single Colour Lightbar Length 1087mm (42.8") LED Colour Green LEDs Lens Colour Clear Lens Compliance ECE-R10, CA13 Input Voltage 12VDC Optic Type D-Fuser Optics Mounting Option Standard Bolt Mount Brackets Cable Type Double Harness (16 Function/4 Power/2 Speaker) LED Quantity 72x LEDs Lighthead Quantity 8x Lightheads IP Rating IPX4K Flash Patterns 12 Flash Patterns Traffic Arrow Patterns 11 Traffic Arrow Net Weight 12.8kg Gross Weight 13.8kg Dummy Bracket Qty 6x Dummy Plates Warranty 5 Year Warranty -
