Legion FIT+ Lightbar, 2138mm (84.2″), 24x AMBER LEDs, CLEAR LENSES, ECE R10, ECE R65 (TA1), IPX4K, D-Fuser Optics, 12 Flash Patterns, Double Harness (16 Function/4 Power), Standard Feet, 12~24VDC.
-
Specifications
Product Specifications
Product code 06270773 Product Name Legion FIT+ 2138mm (84.2") - AC (12~24VDC) Categories Warning Lamps, Lightbars, Legion FIT+ Standard, Legion, Legion FIT+ Product Type Products Configurations (available Take-Downs, Traffic Director, Stop / Tail / Turn, Steady On, Cruise Light, Alley Lights Dimensions Length 2138mm (84") Default Functions Traffic Director - Rear Right Arrow., Right-Side Alley Light, Left-Side Alley Light, Flashing Alleys & Take-Downs, Front Cut-Off, Rear Cut-Off, Take-Down Lights (2 heads, Program Mode, Hi/Low Power (50%, Traffic Director - Rear Left Arrow., ECE-R65 Warning Mode, Flash Pattern for LEDs & TD/Alley Dimensions Height 59mm (2.3") Dimensions Width 331mm (13") Colour Type Single Colour Maximum Current 9.7A@12.8VDC / 5.4A@25.6VDC Operating Temperature -30°C~+65°C Lightbar Length 2138mm (84.2") LED Colour Amber LEDs Lens Colour Clear Lens Compliance ECE-R10, ECE-R65 (TA1) Input Voltage 12VDC~24VDC Optic Type D-Fuser Optics Mounting Option Standard Bolt Mount Brackets Cable Type Double Harness (16 Function/4 Power) LED Quantity 24x LEDs Lighthead Quantity 4x Lightheads IP Rating IPX4K Flash Patterns 12 Flash Patterns Net Weight 15.4kg Gross Weight 16.4kg Warranty 5 Year Warranty -
Spare Parts
-
-
Accessories
-
-
Mounting
-
- Downloads
