EAN: 06270766
Legion FIT+ Lightbar, 1838mm (72.4″), 24x RED LEDs, CLEAR LENSES, ECE R10, ECE R65 (TR1), IPX4K, D-Fuser Optics, 12 Flash Patterns, 2 Cable Harness (16 Function/4 Power), Standard Feet, 12~24VDC.
-
Specifications
Product Specifications
Product code 06270766 Product Name Legion FIT+ 1838mm (72.4") - RC (12~24VDC) Categories Warning Lamps, Lightbars, Legion FIT+ Standard, Legion, Legion FIT+ Product Type Products Configurations (available Cruise Light, Alley Lights, Take-Downs, Traffic Director, Stop / Tail / Turn, Steady On Default Functions Traffic Director - Rear Left Arrow., Traffic Director - Rear Right Arrow., Right-Side Alley Light, Left-Side Alley Light, Flashing Alleys & Take-Downs, Take-Down Lights (2 heads, Front Cut-Off, Hi/Low Power (50%, Rear Cut-Off, Program Mode, ECE-R65 Warning Mode, Flash Pattern for LEDs & TD/Alley Dimensions Height 59mm (2.3") Dimensions Width 331mm (13") Colour Type Single Colour Maximum Current 9.7A@12.8VDC / 5.4A@25.6VDC Operating Temperature -30°C~+65°C Lightbar Length 1838mm (72.4") LED Colour Red LEDs Lens Colour Clear Lens Compliance ECE-R10 Optic Type D-Fuser Optics Input Voltage 12VDC~24VDC Mounting Option Standard Bolt Mount Brackets Cable Type 2 Cable Harness (16 Function/4 Power) LED Quantity 24x LEDs Lighthead Quantity 4x Lightheads IP Rating IPX4K Flash Patterns 21 Flash Patterns Net Weight 15.4kg Gross Weight 16.4kg Warranty 5 Year Warranty -
Spare Parts
-
-
-
-
- Lightheads
- Warning
- Single Colour
- 3 Pin Connector
- Fresnel Optics
-
- Lightheads
- Take-Down
- Single Colour
- 3 Pin Connector
- Spot Optics
-
- Lightheads
- Take-Down
- Single Colour
- 3 Pin Connector
- Spot Optics
-
- Lightheads
- Take-Down
- Single Colour
- 3 Pin Connector
- Spot Optics
-
- Lightheads
- Take-Down
- Single Colour
- 3 Pin Connector
- Spot Optics
-
- Lightheads
- Stop/Tail/Turn (STT)
- ECE-R7
- Split Colour
- Clear Lens
-
-
-
-
-
-
- Lightheads
- Warning
- Single Colour
- 3 Pin Connector
- D-Fuser Optics
-
-
-
Accessories
-
- Connectors
- Polycarbonate (PC)
- 9 Pin Connector
- 1 Cable Harness (8 Function/2 Power)
-
-
Mounting
-
- Powder-Coated Aluminium
- Low Profile Flat Wide Feet
- Black
-
- Powder-Coated Aluminium
- Low Profile Flat Narrow Feet
- Black
-
-
- Powder-Coated Aluminium
- MS3 - Extrusion Bracket
- Black
-
- Powder-Coated Aluminium
- MS3 - A006 Mounting Bracket
- Black
-
- Powder-Coated Aluminium
- Mount Kit (Adjustable A006)
- Black
-
- Powder-Coated Aluminium
- Mount Kit (Adjustable Bolt)
- Black
-
- Powder-Coated Aluminium
- Low Profile Flat Wide Feet
- Black
-
- Powder-Coated Aluminium
- Low Profile Flat Narrow Feet
- Black
-
- Powder-Coated Aluminium
- Standard Bolt Mount Brackets
- Black
-
- Downloads
