Legion FIT Lightbar, 1838mm (72.4″), 24x AMBER LEDs, AMBER LENSES, ECE R10, ECE R65 (TA1), IPX4K, D-Fuser Optics, 7 Flash Patterns, Single Harness (2 Function/2 Power), Standard Feet, 12~24VDC.
-
Specifications
Built-in selectable flash patterns.
Easy maintenance and lighthead replacement.
Multi-voltage input 12-24VDC with EMC compliance.
Non-volatile memory recalls last flash pattern used at power up.
Solid aluminium base for best rigidity and heat dissipation.
Reverse polarity protection.Product Specifications
Product code 06330286 Product Name Legion FIT 1838mm (72.4") - AA (12~24VDC) Categories Warning Lamps, Legion FIT Standard, Legion FIT, Legion, Lightbars Product Type Products Default Functions Hi/Low Power (50%, ECE-R65 Warning Mode Dimensions Length 1828.8mm (72") Dimensions Height 59mm Dimensions Width 331mm Colour Type Single Colour Maximum Current 11.3A@12.8VDC / 6.4A@25.6VDC Lightbar Length 1838mm (72.4") LED Colour Amber LEDs Lens Colour Amber Lens Compliance ECE-R10, ECE-R65 (TA1), SAE J845 Class 1, California Title 13 Input Voltage 12VDC~24VDC Optic Type D-Fuser Optics Mounting Option Standard Bolt Mount Brackets Cable Type Single Harness (2 Function/2 Power/2 Speaker) LED Quantity 24x LEDs Lighthead Quantity 4x Lightheads IP Rating IPX4K Flash Patterns 7 Flash Patterns Warranty 5 Year Warranty -
