Legion Dual Colour Lightbar, 1087mm (42.8″), 48x BLUE/RED LEDs, CLEAR LENS, ECE R10, ECE R65 (TB2), IPX4K, D-Fuser Optics, 12 Flash Patterns, Double Harness (16 Function/4 Power), Standard Feet, 12VDC.
-
Specifications
Integrated Take-down Light and Alley Light options.
Full dual colour lightheads for instant change between colours.
New improved D-Fuser optic with SAE Class 1 and ECE R65 certified performance.
Solid aluminium base plate for best rigidity and heat dissipation.
Long life LEDs technology rated to 100,000 hours of operation.
Reverse polarity protection.Product Specifications
Product code 06360023 Product Name Legion DC 1087mm (42.8") - BR (12VDC) Categories Warning Lamps, Legion Dual Colour Standard, Lightbars, Legion Dual Colour, Legion Product Type Products Configurations (available Traffic Director, Stop / Tail / Turn, Steady On, Cruise Light, Alley Lights, Take-Downs Default Functions Hi/Low Power (50%, Right-Side Alley Light, Left-Side Alley Light, Steady On, Flashing Alleys & Take-Downs, Front Cut-Off, Rear Cut-Off, Program Mode, Traffic Director - Rear Left Arrow., Take-Down Lights (2 heads, Traffic Director - Rear Right Arrow., ECE-R65 Warning Mode, Flash Pattern for LEDs & TD/Alley Dimensions Length 1087mm (42.8") Dimensions Height 59mm Dimensions Width 331mm Colour Type Dual Colour Maximum Current 16.7A@12.8VDC Operating Temperature -30°C~+65°C Lightbar Length 1087mm (42.8") LED Colour Blue LEDs, Red LEDs Software Version (Default) CA Software (16 Wire Modes, 4 Power Wires, 2 Cable Harness Fuse Rating 35A Lens Colour Clear Lens Compliance ECE-R10, ECE-R65 (TB2), SAE J845 Class 1, California Title 13 Input Voltage 12VDC Optic Type D-Fuser Optics Mounting Option Standard Bolt Mount Brackets Cable Type Double Harness (16 Function/4 Power/2 Speaker) LED Quantity 48x LEDs Lighthead Quantity 4x Lightheads IP Rating IPX4K Flash Patterns 12 Flash Patterns Traffic Arrow Patterns 11 Traffic Arrow Dummy Bracket Qty 10x Dummy Plates Warranty 5 Year Warranty -
