Specifications
Product Specifications
Product code 01100532 Product Name Horizon Traffic Director (10 Lighthead) - AW5 Categories Warning Lamps, Horizon, Horizon (Single Colour), Traffic Advisors Product Type Products Dimensions Height 32mm Dimensions Width 53mm Colour Type Single Colour Storage Temperature -40°C - +75°C Maximum Current 6.88A@12VDC / 3.44A@24VDC Operating Temperature -30°C~+65°C Maximum Power 82.4W Traffic Advisor Length 0855mm LED Colour Amber LEDs, White LEDs Fuse Rating 7.5A@12VDC / 4.0A@24VDC Lens Colour Clear Lens Traffic Director Functions Traffic Arrow, Warning Mode, End Flashers Compliance ECE-R10, ECE-R65 (XA1), CISPR25, SAE J595 Class 1, California Title 13 Input Voltage 12VDC~24VDC Optic Type Horizon Optics Mounting Option 2-Bolt Mount Cable Type Single Harness (6 Function/2 Power) LED Quantity 48x LEDs Lighthead Quantity 8x Lightheads IP Rating IPX7 Flash Patterns 50 Flash Patterns Traffic Arrow Patterns 11 Traffic Arrow Wire Length 3000mm Mounting Orientation Horizontal Warranty 5 Year Warranty -
