Specifications
Product Specifications
Product code 02010304 Product Name HB6 Lamp (Warning-White/Halo-Amber) Categories Lighting, Directionals, Halo Blitz, Modules Product Type Products Dimensions Length 132mm Dimensions Height 50mm Dimensions Width 19mm Bezel Colour Black Colour Type Single Colour Maximum Current 1.35A@12VDC / 0.75A@24VDC Storage Temperature -40°C - +75°C Operating Temperature -40°C~+65°C Maximum Power 18W LED Quantity (Halo-Ring/Stripe) 18x (Halo-Ring/Stripe) LEDs LED Colour White LEDs Halo Ring Colour Amber Halo Ring Fuse Rating 2A Lens Colour Clear Lens Compliance ECE R10, ECE R91, SAE J592 Class 1, SAE J595 Class 1, SAE J2042, California Title 13 Input Voltage 12VDC~24VDC Optic Type T.I.R Optics Mounting Option Surface Mount Cable Type Cable (Pigtail) LED Quantity 6x LEDs IP Rating IPX8 Flash Patterns 14 Flash Patterns Wire Length 250mm Conductor Cross-Section 0.5mm² (20AWG) Warranty 5 Year Warranty - Downloads
