Specifications
Unique optical design for efficient and powerful output.
Universal angle adjustable bracket allows diverse mounting options.
Solid aluminium housing for best heat dissipation and maximum durability.
Weatherproof and vibration resistant design for internal or external use.
Non-volatile memory recalls last flash pattern used at power up.
Multi-units synchronization in simultaneous or alternating flash.
Long life LEDs rated to 100,000 hours of operation.
Reverse polarity protection.Product Specifications
Product code 02180083 Product Name ES6 Warning Lighthead (Vertical) - White Categories Lighting, ES6, Edge Saber, Modules Product Type Products Dimensions Length 129mm Dimensions Height 16mm Dimensions Width 27mm Colour Type Single Colour Maximum Current 1.14A@12VDC / 0.57A@24VDC Maximum Power 13.7W LED Colour White LEDs Fuse Rating 2A Lens Colour Clear Lens Compliance ECE R10, SAE J595 Class 1, California Title 13 Input Voltage 12VDC~24VDC Optic Type T.I.R Optics Mounting Option L-Bracket, Universal Bracket Cable Type Cable (Pigtail) LED Quantity 6x LEDs Flash Patterns 23 Flash Patterns IP Rating IPX8 Wire Length 250mm Mounting Orientation Vertical Conductor Cross-Section 0.5mm² (20AWG) Warranty 5 Year Warranty -
