Aegis HE Lightbar, 1678mm (66.1″), 36x BLUE LEDs, BLACK COVERS, ECE R10, ECE R65 (TB2), IPX4K, Full Functionality, D-Fuser Optics, 15 Flash Patterns, Double Harness (16 Function/4 Power), Standard Feet, 12VDC.
-
Specifications
3.25″ (83mm) thickness, broad visibility and powerful output.
Modern design, with a solid, sturdy look to best fit your vehicle.
New generation optics that meets ECE R65, SAE and NFPA.
Control your work-site with a flick of the switch.Product Specifications
Product code 06030216 Product Name Aegis HE 1678mm (66.1") - BK (12VDC) Categories Warning Lamps, Aegis High End, Lightbars, Aegis HE Standard, Aegis Product Type Products Configurations (available Steady On, Alley Lights, Take-Downs Default Functions Flashing Alleys & Take-Downs, Front Cut-Off, Rear Cut-Off, Program Mode, Take-Down Lights (2 heads, Traffic Director - Rear Left Arrow., Hi/Low Power (50%, Traffic Director - Rear Right Arrow., Right-Side Alley Light, Left-Side Alley Light, ECE-R65 Warning Mode, Flash Pattern for LEDs & TD/Alley Dimensions Length 1678mm (66") Dimensions Height 83mm Dimensions Width 310mm Colour Type Single Colour Maximum Current 29.3A@12.8VDC Lightbar Length 1678mm (66.1") LED Colour Blue LEDs Fuse Rating 40A Cover Colour Black Covers Lens Colour Clear Lens Compliance ECE-R10, ECE-R65 (TB2), SAE J845 Class 1, California Title 13 Input Voltage 12VDC Optic Type D-Fuser Optics Mounting Option Standard Bolt Mount Brackets Cable Type Double Harness (16 Function/4 Power) LED Quantity 36x LEDs Lighthead Quantity 4x Lightheads IP Rating IPX4K Flash Patterns 15 Flash Patterns Traffic Arrow Patterns 11 Traffic Arrow Dummy Bracket Qty 18x Dummy Plates Warranty 5 Year Warranty -
