Aegis HE Lightbar, 1522mm (59.9″), 36x BLUE LEDs, BLACK COVERS, ECE R10, ECE R65 (TB2), IPX4K, Full Functionality, D-Fuser Optics, 15 Flash Patterns, Double Harness (16 Function/4 Power), Standard Feet, 24VDC.
-
Specifications
3.25″ (83mm) thickness, broad visibility and powerful output.
Modern design, with a solid, sturdy look to best fit your vehicle.
New generation optics that meets ECE R65, SAE and NFPA.
Control your work-site with a flick of the switch.Product Specifications
Product code 06030599 Product Name Aegis HE 1522mm (59.9") - BK (24VDC) Categories Warning Lamps, Aegis High End, Lightbars, Aegis HE Standard, Aegis Product Type Products Configurations (available Take-Downs, Steady On, Alley Lights Default Functions Flashing Alleys & Take-Downs, Front Cut-Off, Rear Cut-Off, Program Mode, Take-Down Lights (2 heads, Hi/Low Power (50%, Traffic Director - Rear Left Arrow., Traffic Director - Rear Right Arrow., Right-Side Alley Light, Left-Side Alley Light, ECE-R65 Warning Mode, Flash Pattern for LEDs & TD/Alley Dimensions Length 1522mm (60") Dimensions Height 83mm Dimensions Width 310mm Colour Type Single Colour Lightbar Length 1522mm (59.9") LED Colour Blue LEDs Cover Colour Black Covers Lens Colour Clear Lens Compliance ECE-R10, ECE-R65 (TB2), SAE J845 Class 1, California Title 13 Input Voltage 24VDC Optic Type D-Fuser Optics Mounting Option Standard Bolt Mount Brackets Cable Type Double Harness (16 Function/4 Power) LED Quantity 36x LEDs Lighthead Quantity 4x Lightheads IP Rating IPX4K Flash Patterns 15 Flash Patterns Traffic Arrow Patterns 11 Traffic Arrow Dummy Bracket Qty 16x Dummy Plates Warranty 5 Year Warranty -
