Aegis HE Lightbar, 1366mm (53.8″), 36x AMBER LEDs, AMBER COVERS, ECE R10, ECE R65 (TA2), IPX4K, Full Functionality, D-Fuser Optics, 15 Flash Patterns, Double Harness (16 Function/4 Power), Standard Feet, 12VDC.
-
Specifications
3.25″ (83mm) thickness, broad visibility and powerful output.
Modern design, with a solid, sturdy look to best fit your vehicle.
New generation optics that meets ECE R65, SAE and NFPA.
Control your work-site with a flick of the switch.Product Specifications
Product code 06030100 Product Name Aegis HE 1366mm (53.8") - AA (12VDC) Categories Lighting, Aegis High End, Lightbars, Aegis HE Standard, Aegis Product Type Products Configurations (available Take-Downs, Steady On, Alley Lights Default Functions Flashing Alleys & Take-Downs, Front Cut-Off, Rear Cut-Off, Program Mode, Traffic Director - Rear Left Arrow., Take-Down Lights (2 heads, Traffic Director - Rear Right Arrow., Hi/Low Power (50%), Right-Side Alley Light, Left-Side Alley Light, ECE-R65 Warning Mode, Flash Pattern for LEDs & TD/Alley Dimensions Height 83mm Dimensions Width 310mm Colour Type Single Colour Maximum Current 25.3A@12.8VDC Lightbar Length 1366mm (54") LED Colour Amber LEDs Cover Colour Amber Covers Fuse Rating 35A Lens Colour Clear Lens Compliance ECE R10, ECE R65 - TA2, SAE J845 Class 1, California Title 13 Input Voltage 12VDC Optic Type D-Fuser Optics Mounting Option Standard Bolt Mount Brackets Cable Type Double Harness (16 Function/4 Power) LED Quantity 36x LEDs Lighthead Quantity 4x Lightheads Flash Patterns 15 Flash Patterns IP Rating IPX4K Traffic Arrow Patterns 11 Traffic Arrow Wire Length 4800mm Dummy Bracket Qty 14x Dummy Plates Warranty 5 Year Warranty -
