EAN: 06030094
Aegis HE Lightbar, 1210mm (47.6″), 36x BLUE LEDs, BLACK COVERS, ECE R10, ECE R65 (TB2), IPX4K, Full Functionality, D-Fuser Optics, 15 Flash Patterns, 2 Cable Harness (16 Function/4 Power), Standard Feet, 12VDC.
-
Specifications
3.25″ (83mm) thickness, broad visibility and powerful output.
Modern design, with a solid, sturdy look to best fit your vehicle.
New generation optics that meets ECE R65, SAE and NFPA.
Control your work-site with a flick of the switch.Product Specifications
Product code 06030094 Product Name Aegis HE 1210mm (47.6") - BK (12VDC) Categories Warning Lamps, Aegis High End, Lightbars, Aegis HE Standard, Aegis Configurations (available Alley Lights, Take-Downs, Steady On Dimensions Length 1210mm (48") Default Functions Flashing Alleys & Take-Downs, Front Cut-Off, Rear Cut-Off, Program Mode, Traffic Director - Rear Left Arrow., Take-Down Lights (2 heads, Traffic Director - Rear Right Arrow., Hi/Low Power (50%, Right-Side Alley Light, Left-Side Alley Light, ECE-R65 Warning Mode, Flash Pattern for LEDs & TD/Alley Dimensions Height 83mm (3.25") Dimensions Width 310mm (12.2") Colour Type Single Colour Maximum Current 23.3A@12.8VDC Lightbar Length 1210mm (47.6") LED Colour Blue LEDs Cover Colour Black Covers Fuse Rating 32A Lens Colour Clear Lens Compliance ECE-R10, ECE-R65 (TB2), SAE J845 Class 1, CA13 Input Voltage 12VDC Optic Type D-Fuser Optics Mounting Option Standard Bolt Mount Brackets Cable Type 2 Cable Harness (16 Function/4 Power) LED Quantity 36x LEDs Lighthead Quantity 4x Lightheads Flash Patterns 15 Flash Patterns IP Rating IPX4K Traffic Arrow Patterns 11 Traffic Arrow Net Weight 17.6g Gross Weight 18.6kg Dummy Bracket Qty 12x Dummy Plates Warranty 5 Year Warranty -
Spare Parts
-
- Alley
- Single Colour
- 2 Pin Connector
- White LEDs
- Spot Optics
-
- Take-Down
- Single Colour
- Smaller 3 Pin Connector
- White LEDs
- Spot Optics
-
- Warning
- Single Colour
- Smaller 3 Pin Connector
- Blue LEDs
- Fresnel Optics
-
- Warning
- Single Colour
- Smaller 3 Pin Connector
- Blue LEDs
- Linear Optics
-
- Backlight (ICS)
- Single Colour
- 2x Smaller 3 Pin Connectors
- White LEDs
- 12VDC
-
-
-
-
-
-
-
-
-
- Warning
- Single Colour
- Smaller 3 Pin Connector
- Blue LEDs
- D-Fuser Optics
-
- Warning
- Single Colour
- Smaller 3 Pin Connector
- Blue LEDs
- D-Fuser Optics
-
