EAN: 06080129
Aegis DC H002 Speaker Lightbar, 1210mm (48″), 72x RED/BLUE LEDs, BLACK COVERS, ECE R10, ECE R65 (TR2/TB2), IPX4K, Full Functionality, D-Fuser Optics, 15 Flash Patterns, Double Harness (16 Function/4 Power/2 Speaker), Standard Feet, 12VDC.
-
Specifications
3.25″ (83mm) thickness, broad visibility and powerful output.
Modern design, with solid, sturdy look to best fit your vehicle.
New generation optics that meets ECE R65, SAE and NFPA.
Control your work-site with a flick of the switch.
100w built-in speaker.Product Specifications
Product code 06080129 Product Name Aegis DC H002 Speaker 1210mm (48") - BRK (12VDC) Categories Lighting, Lightbars, Aegis Dual Colour, Aegis DC H002 Speaker, Aegis Product Type Products Configurations (available Alley Lights, Take-Downs, Traffic Director Default Functions Hi/Low Power (50%), Left-Side Alley Light, Flashing Alleys & Take-Downs, Front Cut-Off, Rear Cut-Off, Program Mode, Traffic Director - Rear Left Arrow., Traffic Director - Rear Right Arrow., Take-Down Lights (2 heads, Right-Side Alley Light, ECE-R65 Warning Mode, Flash Pattern for LEDs & TD/Alley Dimensions Height 83mm Speaker Power Rating 100W Dimensions Width 310mm Colour Type Dual Colour Maximum Current 23.3A@12.8VDC Lightbar Length 1210mm (48") Speaker Impedance 10-13 Ohms Speaker Type H002 LED Colour Blue LEDs, Red LEDs Cover Colour Black Covers Lens Colour Clear Lens Compliance ECE R10, ECE R65 - TB2, ECE R65 - TR2, SAE J845 Class 1, California Title 13 Input Voltage 12VDC Optic Type D-Fuser Optics Mounting Option Standard Bolt Mount Brackets Cable Type Double Harness (16 Function/4 Power/2 Speaker) LED Quantity 72x LEDs Lighthead Quantity 4x Lightheads IP Rating IPX4K Flash Patterns 15 Flash Patterns Dummy Bracket Qty 8x Dummy Plates Warranty 5 Year Warranty -
Spare Parts
-
- Lighthead
- Take-Down
- Single Colour
- 6x LEDs
- Smaller 3 Pin Connector
-
- Lighthead
- Alley
- Single Colour
- 3x LEDs
- 2 Pin Connector
-
- Lighthead
- Warning
- Dual Colour
- 12x LEDs
- Smaller 3 Pin Connector
-
-
-
- Base Plate
- Polycarbonate (PC)
- H002
- Middle
- Black
-
-
-
-
- Lighthead
- Warning
- Dual Colour
- 18x LEDs
- Smaller 3 Pin Connector
-
- Lighthead
- Warning
- Dual Colour
- 18x LEDs
- Smaller 3 Pin Connector
-
- Speaker
- 100W
- Aluminium, Acrylonitrile Butadiene Styrene (ABS)
- 100W
- H002
-
-
Mounting
-
- Bracket
- Aluminium
- Low Profile Flat Wide Feet
- Black
-
- Bracket
- Aluminium
- Low Profile Flat Narrow Feet
- Black
-
-
- Bracket
- Aluminium
- MS3 - Extrusion Bracket
- Black
-
- Bracket
- Aluminium
- MS3 - A006 Mounting Bracket
- Black
-
- Bracket
- Mount Kit (Adjustable A006)
- Black
-
- Bracket
- Aluminium
- Mount Kit (Adjustable Bolt)
- Black
-
- Bracket
- Aluminium
- Low Profile Flat Wide Feet
- Black
-
- Bracket
- Aluminium
- Low Profile Flat Narrow Feet
- Black
-
-
-
