EAN: 06060107
Aegis Dual Colour Lightbar, 1210mm (47.6″), 72x AMBER/BLUE LEDs, BLUE COVERS, ECE R10, ECE R65 (TA2/TB2), IPX4K, Full Functionality, D-Fuser Optics, 15 Flash Patterns, 2 Cable Harness (16 Function/4 Power), Standard Feet, 12VDC.
-
Specifications
3.25″ (83mm) thickness, broad visibility and powerful output.
Modern design, with solid, sturdy look to best fit your vehicle.
New generation optics that meets ECE R65, SAE and NFPA.
Control your work-site with a flick of the switch.Product Specifications
Product code 06060107 Product Name Aegis DC 1210mm (47.6") - ABB (12VDC) Categories Warning Lamps, Lightbars, Aegis DC Standard, Aegis Dual Colour, Aegis Configurations (available Traffic Director, Steady On, Alley Lights, Take-Downs Dimensions Length 1210mm (48") Default Functions Flashing Alleys & Take-Downs, Front Cut-Off, Rear Cut-Off, Program Mode, Traffic Director - Rear Left Arrow., Traffic Director - Rear Right Arrow., Right-Side Alley Light, Take-Down Lights (2 heads, Left-Side Alley Light, Hi/Low Power (50%, ECE-R65 Warning Mode, Flash Pattern for LEDs & TD/Alley Dimensions Height 83mm (3.25") Dimensions Width 310mm (12.2") Colour Type Dual Colour Maximum Current 23.3A@12.8VDC Lightbar Length 1210mm (47.6") LED Colour Amber LEDs, Blue LEDs Cover Colour Blue Covers Fuse Rating 32A Lens Colour Clear Lens Compliance ECE-R10, ECE-R65 (TA2), ECE-R65 (TB2), SAE J845 Class 1, CA13 Input Voltage 12VDC Optic Type D-Fuser Optics Mounting Option Standard Bolt Mount Brackets Cable Type 2 Cable Harness (16 Function/4 Power) LED Quantity 72x LEDs Lighthead Quantity 4x Lightheads Flash Patterns 15 Flash Patterns IP Rating IPX4K Traffic Arrow Patterns 11 Traffic Arrow Net Weight 18.6kg Gross Weight 19.6kg Dummy Bracket Qty 12x Dummy Plates Warranty 5 Year Warranty -
Spare Parts
-
- Alley
- Single Colour
- 2 Pin Connector
- White LEDs
- Spot Optics
-
- Take-Down
- Single Colour
- Smaller 3 Pin Connector
- White LEDs
- Spot Optics
-
- Warning
- Dual Colour
- Smaller 3 Pin Connector
- Amber LEDs, Blue LEDs
- Linear Optics
-
- Take-Down
- Single Colour
- Smaller 3 Pin Connector
- White LEDs
- Spot Optics
-
- Dual Layer
- Amber LEDs, Blue LEDs
- Linear Optics, T.I.R Optics
- 12VDC
- Middle Lighthead
-
- Dual Layer
- Blue LEDs, Red LEDs
- Linear Optics, T.I.R Optics
- 12VDC
- Middle Lighthead
-
- Dual Layer
- Blue LEDs, White LEDs
- Linear Optics, T.I.R Optics
- 12VDC
- Middle Lighthead
-
-
-
-
-
- Warning
- Dual Colour
- Smaller 3 Pin Connector
- Amber LEDs, Blue LEDs
- D-Fuser Optics
-
- Warning
- Dual Colour
- Smaller 3 Pin Connector
- Amber LEDs, Blue LEDs
- D-Fuser Optics
-
-
-
